ONKA 150mm2 M12 Screw-in DIN rail connection terminal block with protective cover, gray, 1030088
- Regular price
- €34,32
- Regular price
-
- Sale price
- €34,32
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
Pre-order product
- Description
- Payment methods
- Warranty
M12, 150 mm2, threaded busbar connector / DIN rail terminal with protective cover, gray, ONKA, made in Turkey
Compact ONKA mounting rail connectors provide excellent opportunities for connecting wires of any cross-section. The transparent housing makes it easy to check whether the wires are correctly arranged. Original ONKA quick connectors mean ease of installation and one hundred percent connection reliability.
Technical parameters
Connectable single wire cross-section up to: 150 mm2
Color: gray
Main body insulation material: polyamide (PA6.6)
Contact/bridge material: CK45 steel/copper
Connection position: side/side
Rated voltage: 1000 V
Rated current: 309 A
Operating temperature range from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN 35 mm mounting rail
