12-step Single-phase connection Power factor controller for power factor control in networks with symmetrical loads (TENSE)
The reactive power control relay RGM-12S is designed to reduce inductive power that is not consumed by the load but is drawn from the network. When inductive reactive power is drawn from the network, it intervenes by switching on capacitors of the appropriate value. In this way, it tries to achieve that the Cos phi value reaches the desired level.
7 Different power factor compensation programs
Manual power factor compensation programs
Can only compensate for induction systems
Automatic step measurement
-
Adjustable step activation, release and release times
Adjustable values of voltage and current harmonic signals
Overcompensation and undercompensation alarm values can be set
Voltage, harmonic voltage/current, over and under compensation alarm output
Voltage, current and frequency values can be monitored
Active, reactive and apparent power values can be monitored
Up to the 15th harmonic THD-I can be monitored
Up to the 15th harmonic THD-V can be monitored
It is possible to observe the cosine value
The power factor value can be monitored
Automatic fan output
Smooth aging in stages (in some compensation programs)
